Description
Product Description
- Handheld fiber laser welding machine is 4-10 times faster than traditional TIG/MIG welding.
- Simple operation, even unskilled operators can weld beautiful products.
- Can weld metal products of different materials and thicknesses.
- Smooth and beautiful, the workpiece is not deformed, and the subsequent polishing process is reduced.
- Save you more time and expensive labor costs.
Compare with Traditional Welding
Beginners can get started in 10 minutes, and the welding speed is 4-10 times that of traditional welding,
saving 3-5 professional welders. The energy is concentrated, the thermal deformation is small,
the welding seam is beautiful, the penetration is deep, and the strength is high. It can weld thin materials,
wire filler welding and wireless welding.
High professional and technical requirements, high wages for workers, occupational diseases,
large body injuries, slow welding speed, low efficiency, large heat influence and easy deformation,
thick and irregular welds, requiring secondary polishing, large limitations, and can not weld too thin materials.
Handheld Fiber Laser Welding Machine PK Traditional Welding Machine
| project | Traditional welding | Handheld Fiber Laser Welding Machine |
| Welding speed | Generally | 4-10x faster |
| HeatAffected zone | Large | Small |
| Deformation | Large | Small |
| Bond strength with base material | Common | Excellent |
| Subsequent processing | Polish | No or very little polish |
| Consumables | any | Little |
| Operation difficulty | Complicate | Simple |
| Operator safety | Not safe | Safe |
| Impact on the environment | Pollutional | Enviromental |
| Welding fault tolerance | Good | Good |
| Pendular welding | No | Yes |
| Adjustable spot width | No | Yes |
| Welding quality contrast | Bad | Excellent |
| Adjustable Welding mode | No | Six Mode |
Product Parameters
| project | technical parameter |
| Overall Power | 6KW |
| Laser Power | 1000W |
| Laser wave length | 1080nm |
| Handheld length | 10M |
| Capacity control | 10–100% |
| Swing mode | Six |
| Light class adjustment | 1–5mm |
| Frequency regulation | 1-1000HZ |
| Working voltage | AC 220V ±10% 50HZ |
| Send silk machine | Standard equipped with 1mm welding wire |
| Language | Standard in Chinese, English, Japanese, Korean, Russian, Spain can be customized |
| Package size and weight | 1260*670*1170mm 260KG |
DG-W1000 Laser Welding Capacity
| Material | Thickness
Single side weld |
Thickness
Double side weld |
Thickness
Wire weld |
| Sianless steel | 3mm | 6mm | 2.5mm |
| Galvanized steel | 3mm | 6mm | 2.5mm |
| Mild steel | 3mm | 6mm | 2.5mm |
| Titanium alloy | 3mm | 6mm | 2.5mm |
| Aluminum | 2mm | 4mm | 1.8mm |
| Copper | 1mm | 2mm | 0.8mm |
About us
Shenzhen DaG Technology Industrial Co., Ltd is a laser machinery manufacturers and suppliers.we are in the industry of Laser marking machine, Laser welding machine, Laser cutting machine, Laser cleaning machine. we provide customers with pre-sale and after-sale equipment design and service according to the size of our products，and provide free consulting services during the production process without any problems.
In recent years, companies in the same industry in many countries and regions have also purchased laser marks, laser welding machines, jewelry laser welding machines, 3015/1390 laser cutting machines, pulse/continuous laser cleaning machines and other mechanical equipment.
If you are interested in buying any products, please contact us, we will provide you with the best service and preferential prices.
Our 3in1 Handheld Fiber Laser Welding Machine
